Commercial Indoor IAQ Air Quality Smart Sensor Monitor Multi Pollutant Detection

Commercial Indoor IAQ Air Quality Smart Sensor Monitor Multi Pollutant Detection

Brand Name:	GZAIR
Model Number:	CH6
MOQ:	10
Price:	$29 - $169
Payment Terms:	D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	1000 pieces per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, RoHS, FCC

Communication Option 1:

WiFi-MQTT

Communication Option 2:

Modbus TCP LoRaWan(Option)

Communication Option 3:

BACnet MS/TP, IP(Option)

Communication Option 4:

Modbus RTU/TCP(Option)

Packaging Details:

530*365*265mm/carton

Supply Ability:

1000 pieces per month

Highlight:

Commercial air quality smart sensor

Multi Pollutant air quality smart sensor

IAQ commercial indoor air quality monitor

Product Description

Advanced IAQ Monitor with Touchscreen & Multi-Pollutant Detection

Ensure a cleaner, healthier indoor environment with the Advanced IAQ Monitor with Touchscreen & Multi-Pollutant Detection — your comprehensive solution for real-time air quality insights. Designed for smart homes, offices, schools, and healthcare facilities, this high-performance monitor combines precision sensors with intuitive touchscreen controls to give you full visibility and control over your indoor air.
This all-in-one device continuously monitors key air quality indicators including CO₂, PM2.5, PM1.0, VOCs, Pressure, temperature, and humidity, providing instant feedback on current conditions via a vivid color touchscreen interface. With built-in WiFi connectivity, it syncs seamlessly with your smartphone or desktop app, offering historical data tracking, smart alerts, and remote monitoring — so you’re always in the know, no matter where you are.
Key Features:
High-Resolution Touchscreen Display: Instantly view air quality metrics, trends, and alerts in a sleek, modern layout
Multi-Pollutant Detection: Accurately tracks CO₂, PM2.5, PM1.0, TVOCs, temperature, and humidity
WiFi-Enabled Smart Monitoring: Access data remotely and receive real-time notifications via mobile app
Data Logging & Trend Graphs: Review historical air quality patterns for improved environmental decisions
Customizable Smart Alerts: Set thresholds and get notified when air quality becomes unsafe
Professional & Personal Use: Perfect for residential, educational, commercial, and clinical environments.

Power Supply	USB Supply DC5V; 110-230VAC
Display	320x480 pixels color TFT Capacitive touch
LoRaWAN	868mHz/923mHZ/915mHZ
WiFi	IEEE 802.11b/g/n-2.4ghz
BACnet	MSTP/IP
Modbus	RTU/TCP
Security	WPA/WPA2
Operating temperature	1°C-85°C
Sensors	Co2: 0-5000ppm(±30ppm +3%MV)
	Temperature:-10°C-70°C,(0.5 C 25 C)
	Humidity:0-100%,±3% VOC: 0-60.000 ppb
	Particulate Matter (PM1.5,PM2.5 PM4PM10): 4 KB0-100 μg/m3(±10μg/m3),100-1000(±10%)
	Pressure: 50 to 115 kPa ±1 kPa
Communication	WiFi-MQTT, modbus TCP LoRaWan(Option)
Communication	BACnet MS/TP,IP(Option) Modbus RTU/TCP(Option)
Data protocals	MQTT
Data protocals	Device Configuration Using HTTP Download OTA Updates Via HTTP
NDIR life time	15 Years
Standby power consumption	≤0.5 W
Display dimensions	76.5X52 mm(W/H)
Dimensions(W/H/D)	968632.5(mm)
Weight	≤200g
Enclosure rating	IP 21
Product material	PC+ ABS plastic
